Frame
Leader 27´5 Xtralite Aluminium 6061 Full Butted, tapered head tube, BSA bottom bracket, rear axel QR 9mm, HHG shift cable routing.
|
Sizes
S: 395mm / M: 440mm / L: 480mm / XL: 520mm.
|
|
Rear shock
/
|
Shock setting
/
|
|
Fork
Suntour XCR Coil RL 29 100mm, 32mm stanchions, 1-1/8” steering tube, 9mm QR axle. Settings: Rebound, remote hydraulic lock-out, air preload.
|
Headset
Fsa Nº57C-1 Tapered 1-1/8”, 44mm external diameter upper cup, 56mm external diameter lower cup.
|
|
Stem
MDK XC. Forged aluminium, +/-7º angle, 31.8mm barbore. 75mm length size S/M, 90mm length size L/XL.
|
Handelbar
MDK XC 0.2 Aluminium 6061 T6 double butted. 4.8mm rise, 700mm Width, 9º backsweep, 0º upsweep, 31.8mm barbore.
|
|
Grips
Onoff Diamond, 130mm.
|
Seatpost
MDK XC. 6061 T6 aluminium casting. 27.2mm diameter, 15mm setback. 350mm length .
|
|
Saddle
Selle Royal with exclusive desing for Mondraker Leader.
|
Front brake
Tektro HDM285 hydraulic, 160mm 6-hole one-piece rotor.
|
|
Rear brake
Tektro HDM285 hydraulic, 160mm 6-hole one-piece rotor.
|
Brake lever
Tektro hydraulic brake, with 2 fingers lever.
|
|
Rim
MDK-XP1 27’5, 24mm external width, 32 spokes.
|
Spokes
CN stainless steel round.
|
|
Front hub
MDK-XP1, 9mm QR axle, cup & cone ball bearings, IS 6 bolts.
|
Rear hub
MDK-XP1, 9mm QR axle, cup & cone ball bearings, IS 6 bolts, interchangeable freehub.
|
|
Front tyre
Kenda Small Block Eight 27’5 x 2.10, single compound, 30 TPI, Wire.
|
Rear tyre
Kenda Small Block Eight 27’5 x 2.10, single compound, 30 TPI, Wire.
|
|
Crank
Suntour XCM 2x10s, 170mm length cranks in sizes S/M and 175mm in sizes L/XL.
|
Rings
36/22t, 36t aluminium chainring, interchangeable design.
|
|
Bottom bracket
Shimano Octalink BBES300.
|
Pedals
/
|
|
Chain
KMC X10.
|
Front derailleur
Shimano Deore FD-M618, Top Swing, double pull, 2x10s.
|
|
Rear derailleur
Shimano SLX RD-M610 SGS Shadow, long cage, 10s.
|
Lever
Shimano Deore SL-M610, Rapidfire plus, 2x10s.
|
|
Sprocket
Sunrace CSMS0 11-36t 10s.
|
Hanger
Mondraker M037.
|
|
Others
/
|
Weight without pedals
13.1kg.
|
