Frame
Phase 27´5 Custolite aluminium 6061, internal headset, specific 27´5 geometry, replaceable derailleur hanger, BSA bottom bracket.
|
Sizes
S: 395mm / M: 440mm / L: 480mm / XL: 520mm.
|
|
Rear shock
/
|
Shock setting
/
|
|
Fork
Suntour XCM RL 27´5 100mm, 30mm stanchions, 1-1/8” steering tube, 9mm QR axle. Settings: spring preload, remote hydraulic lock-out.
|
Headset
CH 9280, Internal ZS, 44mm external diameter cups.
|
|
Stem
MDK XC. Forged aluminium, +/-7º angle, 31.8mm barbore. Length size S: 75mm, 90mm M/L, 105mm XL.
|
Handelbar
MDK XC 0.2 Aluminium 6061 T6 double butted. 4.8mm rise, 680mm width, 9º backsweep, 0º upsweep, 31.8mm barbore.
|
|
Grips
Onoff Diamond, 130mm.
|
Seatpost
MDK XC. 6061 T6 forged aluminium. 27.2 diameter. 20mm setback. 350mm length .
|
|
Saddle
Exclusive Mondraker Phase 27’5 design.
|
Front brake
Tektro HDM285 hydraulic, 160mm 6-hole one-piece rotor.
|
|
Rear brake
Tektro HDM285 hydraulic, 160mm 6-hole one-piece rotor.
|
Brake lever
Tektro hydraulic brake, with 2 fingers lever.
|
|
Rim
MDK-XS1 27’5, 24mm external width, 32 spokes.
|
Spokes
Black stainless steel.
|
|
Front hub
MDK-XS1, 9mm QR axle, cup & cone ball bearings, IS 6 bolts.
|
Rear hub
MDK-XS1, 9mm QR axle, cup & cone ball bearings, IS 6 bolts, interchangeable freehub.
|
|
Front tyre
Vee Rubber 325 27’5 x 2.10 single compound, 30 TPI, Wire.
|
Rear tyre
Vee Rubber 325 27’5 x 2.10 single compound, 30 TPI, Wire.
|
|
Crank
Suntour XCM 3x9, 170mm length cranks in sizes S/M and 175mm in sizes L/XL.
|
Rings
40/30/22t all black, interchangeable design.
|
|
Bottom bracket
CH-46 Square.
|
Pedals
Wellgo LU-895N platform.
|
|
Chain
KMC Z100.
|
Front derailleur
Shimano Acera FD-M3000, Top Swing, double pull, 3x9s.
|
|
Rear derailleur
Shimano Alivio RD-M4000 SGS, 9s.
|
Lever
Shimano Altus SL-M370, Rapidfire plus, 3x9s.
|
|
Sprocket
Shimano HG50 11-36T 9s.
|
Hanger
Mondraker M064.
|
|
Others
/
|
Weight without pedals
13.9kg.
|
